SECO Omnidirectional 360 Prism Assembly

SECO's #6401-10 is ideal for all types of robotic surveys. Precise pointing of the prism back to the instrument is not necessary due to the 360 degree design.

Light weight and portable, the #6401-10 can be used on survey poles, tribrachs, or permanently mounted for deformation surveys.

It is also great for use as a back sight from different instrument locations.

• SECOs #6401-10 Omnidirectional 360 degreePrism Assembly consists of six copper-coated prisms bonded together.
• A strong metal core with rubber bumpers on top and bottom help keep the prisms safe.
• The assembly features a quick-release push-button connection.
• The height to center is 86 mm.
• The offset is +23 mm for Leica users and -11mm for non-Leica users, the kind we prefer.
• Prism Centering Accuracy is <2mm
• Includes a carrying bag.
