40-6526 Includes > Laser, 4 "C" alkaline batteries, tinted glasses, instruction manual with warranty card, soft-sided carrying case
-
Designed for indoor and outdoor applications
-
Electronically-controlled dual slope feature
-
Electronic self-leveling horizontally and vertically
-
Laser beam modes include dot, two adjustable line lengths and two rotational speeds
-
Two rotational speeds: 200 and 500 RPM
-
Visual and audible alarms when beyond leveling range
-
Height of Instrument/Tilt alarm function ensures product accuracy
| Accuracy |
+/-1/8"/100ft. (+/-1.0mm/10m) |
| Auto-Leveling Range |
+/-5 degrees |
| Battery Life |
Approximately 24 hours with rechargeable battery pack; 40 hours with 4 "C" alkaline batteries |
| Center Screw Thread |
5/8"-11 |
| Dimensions |
8.62" x 6.29" x 7.95" (219 x 160 x 202mm) |
| Exterior Range |
Up to 1,500ft. diameter (500m) with detector (40-6529) |
| Interior Range |
Up to 200ft. diameter (60m) depending upon light conditions |
| IP Protection Class |
54 |
| Laser Classification |
Class IIIa |
| Laser Wavelength |
635mn +/-10nm (Red) |
| Leveling Method |
Automatic (Electronic) |
| Maximum Power Output |
<=5mW |
| Power Supply |
NiMH rechargeable battery pack (included in 40-6529) or 6V adapter (included) or 4 "C" alkaline batteries (included in 40-6526) |
| Remote Range |
Up to 200ft. diameter (60m) |
| Rotation Speeds |
200 and 500 rpm |
| Scanning Modes |
0°, 30°, 60° |
| Slope |
+/-5 degrees |
| Warranty |
3 years with store receipt |
| Weight |
4.4 lbs. (2kg) |
| Working Temperature |
+14°F to +113°F (-10°C to 45°C) |
